BOX compression tester (PT-103)

Compliance standards

IS :7028 (PART VI), IS : 7028 (PART IX), ASTM D4577, ASTM D642, TAPPI :T804

Salient Features

  • Digital Electro - mechanical model
  • PLC & HMI Touch screen display
  • Direct Display of Load / Collapsing Force
  • No Calculations Required
  • Auto-stop upon completion of Test
  • Unlimited programmable memories
  • Continuous rate of Loading
  • 2/4 Load cells for highest accuracy
  • Selectable compression units in N, kgf or lbf
  • RS-232 data output
  • PC Closed Loop Control

Technical Specifications

  • Capacity : 1000 Kgf (10 KN
  • Least Count : 1 Kgf (0.01 KN)
  • Suitable for a Testing Range of : 10 - 1000 Kgf
  • Auto-Calibration facility : At 100 Kgf (1 KN)
  • Speed : 10 ± 3 mm/min (As per TAPPI)
  • Power Supply : 230 Volts, 50 Hz, Single Phase, AC Supply
  • Available platform sizes : 450 x 450 mm, 600 x 600 mm, 1000 x 1000 mm, 2000 x 1000 mm

Available in following sizes

Platform Size 450 X 450 MM Platform 600 X 600 MM Platform 1000 X 1000 MM Platform 2000 X 1000 MM Platform
Model Nos. PT-103DPA PT-103DPB PT-103DPC PT-103DPD

D: Digital, P: Powder Coated
